Doble
Stoil Cell
The option allows testing that the oil characteristics of isolation are met and that there is no contamination. The option is made of a suitable glass container with electrodes; the electrodes are connected to the option TD 5000 for the test execution.
Details
Oil cell for the HV test of dielectric oil
The option allows testing that the oil characteristics of isolation are met and that there is no contamination. The option is made of a suitable glass container with electrodes; the electrodes are connected to the option TD 5000 for the test execution. The test result, displayed by STS 5000, is the oil Tan Delta.
Main features
Maximum test voltage: 12 kV
Cell volume: about 1l
Capacitance of the empty cell: 60 pF.
Tests performed
Tangent Delta
Application
Power transformer
