The MTS-5100 is an all-in-one relay test set with a direct front panel interface for all functions, without exception.

The ideal integrated system for testing and calibration of protection and control relays, simulation of power system phenomena, and verification of voltage, current, phase, and power transducers.

FEATURES OF Protective Relay Test System  MTS-5100

• Large 10.1” display
• Six AC/DC Currents
• Four AC/DC Voltages
• 12 Contact / 0-250Vrms Voltage inputs
• Four contact outputs
• Transducer voltage/input
• GPS input (antenna included)
• IRIG input, IRIG output
• IEEE 61850 GOOSE messaging
